Características VTM42:
BOMBAS DA DIREÇÃO DE PODER
* fonte de energia compacta para os conjuntos de direção
* controle integral do relevo e de fluxo
* eficiência elevada
* projeto equilibrado do cartucho
* operação quieta
1 tipo bomba da aleta do móbil
2 séries
Flange de montagem 3
Flange de montagem de A-SAE A
(Omita se não exigido)
Tamanho de 4 anéis – entrega
(Avaliação do SAE – 1200 RPM & barra 7 (100psi))
10 – 1,0 USgpm 40 – 4,0 USgpm
15 – 1,5 USgpm 50 – 5,0 USgpm
20 – 2,0 USgpm 60 – 6,0 USgpm
5 caudais controlados
(1500 na barra do RPM &7 (100psi))
15 – 6 L/MIN (1,5 USgpm)
20 – 8 L/MIN (2 USgpm)
25 – 9,5 L/MIN (2,5 USgpm)
30 – 11 L/MIN (3 USgpm)
35 – 13 L/MIN (3,5 USgpm)
40 – 15 L/MIN (4 USgpm)
45 – 17 L/MIN (4,5 USgpm)
50 – 19 L/MIN (5 USgpm)
55 – 21 L/MIN (5,5 USgpm)
60 – 23 L/MIN (6 USgpm)
65 – 25 L/MIN (6,5 USgpm)
70 – 26,5 L/MIN (7 USgpm)
75 – 28 L/MIN (7,5 USgpm)
Ajuste da válvula de escape 6
(pressão de rachamento)
barra 05 – 35 (500 libras por polegada quadrada)
barra 07 – 52 (750 libras por polegada quadrada)
barra 10 – 70 (1000 libras por polegada quadrada)
barra 12 – 86 (1250 libras por polegada quadrada)
barra 15 – 100 (1500 libras por polegada quadrada)
barra 17 – 120 (1750 libras por polegada quadrada)
barra 20 – 140 (2000 libras por polegada quadrada)
Filtro de 7 reservatórios
F – filtre pelo contrário se padrão confundem.
Omita se não exigido.
8 reservatório ou distribuidor
reservatório de 07 – 1147 mL (70 in3)
(Omita para VTM42A)
reservatório de 11 – 1884 mL (115 in3)
(Omita para VTM42A)
Miliampère – Distribuidor sem tubo do desvio
MB – Distribuidor com tubo do desvio
DM – Distribuidor com o connetion do tanque 90o
EU – Distribuidor do molde sem tubo do desvio
MF – Distribuidor do molde com tubo do desvio
NÃO – Nenhum (fechamento do transporte somente)
Rotação de 9 eixos
R - Assistente (sentido horário)
L – mão esquerda (anti-horário)
Tipo de 10 eixos
1 – rosqueado (VTM42 somente)
38 – ranhurado (VTM42A somente)
Projeto 11
Assunto a mudar. As dimensões da instalação permanecem as mesmas para projetos -10 a -19.
Os valores basearam em usar o tipo antiusura SUS do óleo de petróleo 150 em 100°F e em 0 libras por polegada quadrada de pressão de entrada.
| MODELO | TAMANHO DO ANEL | DESLOQUE. | VELOCIDADE MÁXIMA - RPM | MÁXIMO | APROXIMADAMENTE. | |||||
| em 3 r | ||||||||||
| SÉRIE | (ENTREGA USgpm @ 1200 R/MIN | @100 LIBRA POR POLEGADA QUADRADA | @1500 LIBRA POR POLEGADA QUADRADA | @2000 LIBRA POR POLEGADA QUADRADA | PRESSÃO | PESO | ||||
| & 100 libras por polegada quadrada) | (cm 3 r) | BARRA 7 | (BARRA 100) | (BARRA 140) | LIBRA POR POLEGADA QUADRADA (BARRA) | libras. (quilograma.) | ||||
| 1 | 0,21 | (3,4) | 7000 | 5000 | 4250 | |||||
| 1,5 | 0,31 (5,1) | 7000 | 4500 | 4000 | ||||||
| 2 | 0,38 (6,2) | 7000 | 4200 | 3800 | 2000 | 14 (6,4) | ||||
| VTM42 | 4 | 0,79 (12,9) | 7000 | 2800 | 2800 | (140) | ||||
| 5 | 0,96 | (15,7) | 6000 | 2600 | 2300 | |||||
| 6 | 1,18 (19,3) | 5000 | 2500 | 2000 | ||||||
| 426045-R | VTM42-40-15-20-MB-R1-14 |
| 574546-r | VTM42-40-40-10-MF-R1-14 |
| 402921-R | VTM42-50-20-12-NO-R1-14 |
| 574083-R | VTM42-50-50-20-MJ-R1-14 |
| 478265-R | VTM42-60-20-15-MF-R1-14 |
| 502628-R | VTM42-40-35-15-11-R1-14 |
| 431225-R | VTM42-10-15-05-MB-R1-14 |
| 02-143257 | VTM42-10-15-07-11-*1-14-ECN-1/13/ |
| 02-143221 | VTM42-10-15-07-11-*1-14-ECN-1/13/9 |
| 02-143257-R | VTM42-10-15-07-11-R1-14-ECN-1/13/ |
| 02-143221-R | VTM42-10-15-07-11-R1-14-ECN-1/13/9 |
| 574003-R | VTM42-10-15-10-F11-R1-14 |
| 574008-R | VTM42-10-15-20-F11-R1-14 |
| 723AR00003A | VTM42-10-30-20-F07-R1-14 |
| 574223-R | VTM42-10-35-07-F07-R1-14-S80-S80-VTM42-10-35-07-F07 |
| 02-160194-R | VTM42-10-35-07-NO-R1-14 |
| 02-348001-R | VTM42-10-40-15-F11-R1-14 |
| 574343-R | VTM42-10-60-15-NO-R1-14 |
| 574267-R | VTM42-10-65-20-MA-R1-14 |
| 452608-R | VTM42-10-75-07-N0-R1-14 |
| 426005-R | VTM42-10-N0-AJ-07-R1-14-S73-S73-VTM42-10-N0-AJ-07-R1 |
| 426006-R | VTM42-10-N0-AJ-11-R1-14-S73-S73-VTM42-10-N0-AJ-11-R1 |
| 882996-R | VTM42-15-15-10-NO-R1-14 |
| 477516-L | VTM42-15-15-15-MA-L1-14 |
| 574354-L | VTM42-15-20-05-F07-L1-14 |
| 574354-R | VTM42-15-20-05-F07-R1-14 |
| 413658-R | VTM42-15-30-07-N0-R1-14 |
| 478256-R | VTM42-15-30-10-N0-R1-14 |
| 431106-R | VTM42-15-35-07-F07-R1-14 |
| 574222-R | VTM42-15-35-07-F07-R1-14-S80-S80-VTM42-15-35-07-F07 |
| 574045-L | VTM42-15-40-12-MF-L1-14 |
| 574052-R | VTM42-15-75-20-NO-R1-14 |
| 723AR00001A | VTM42-20-15-10-11-R1-14 |
| 426010-R | VTM42-20-15-10-N0-R1-14 |
| 431103-R | VTM42-20-15-12-NO-R1-14 |
| 393181-R | VTM42-20-15-20-F11-R1-14 |
| 02-142384-R | VTM42-20-20-06-F11-R1-14 |
| 452487-R | VTM42-20-20-10-N0-R1-14 |
| 431370-R | VTM42-20-20-15-N0-R1-14 |
| 02-151977-R | VTM42-20-25-10-MB-R1-14 |
| 426084-R | VTM42-20-30-15-F07-R1-14 |
| 574871-R | VTM42-20-40-15-MD-R1-14 |
| 431309-R | VTM42-20-50-15-11-R1-14 |
| 503118-R | VTM42-20-55-17-N0-R1-14 |
| 574234-R | VTM42-20-60-07-NO-R1-14 |
| 02-315027-L | VTM42-20-60-15-F11-L1-14 |
| 413775-R | VTM42-20-65-17-MA-R1-14 |
| 02-142515-R | VTM42-20-75-05-NO-R1-14 |
| 574019-R | VTM42-20-75-15-F11-R1-14 |
| 876235-L | VTM42-20-75-15-MA-L1-14 |
| 431328-R | VTM42-20-75-15-N0-R1-14 |
| 452478-R | VTM42-20-75-20-F11-R1-14 |
| 574053-R | VTM42-20-75-20-NO-R1-14 |
| 453147-R | VTM42-30-12-F07-R1-14 |
| 574357-R | VTM42-40-15-10-F07-R1-14 |
| 408275-R | VTM42-40-15-10-MF-R1-14 |
| 385988-R | VTM42-40-15-10-N0-R1-14 |
| 386001-L | VTM42-40-15-15-ME-L1-14 |
| 386001-R | VTM42-40-15-15-ME-R1-14 |
| 02-159890-L | VTM42-40-20-07-MF-L1-14 |
| 02-159890-R | VTM42-40-20-07-MF-R1-14 |
| 431224-R | VTM42-40-20-15-N0-R1-14 |
| 574389-R | VTM42-40-20-20-F11-R1-14 |
| 723AR00004A | VTM42-40-20-20-MR-R1-14 |
| 431213-R | VTM42-40-20-20-N0-R1-14 |
| 398754-R | VTM42-40-25-10-F11-R1-14 |
| 401100-L | VTM42-40-25-10-N0-L1-14 |
| 401100-R | VTM42-40-25-10-N0-R1-14 |
| 431353-R | VTM42-40-25-12-ME-R1-14 |
| 394308-L | VTM42-40-25-12-N0-L1-14 |
| 394308-R | VTM42-40-25-12-NO-R1-14 |
| 385941-R | VTM42-40-25-15-F07-R1-14 |
| 413747-R | VTM42-40-25-15-F11-R1-14 |
| 385940-R | VTM42-40-25-15-N0-R1-14 |
| 413727-R | VTM42-40-25-17-F11-R1-14 |
| 426011-R | VTM42-40-25-17-N0-R1-14 |
| 401121-L | VTM42-40-25-20-F07-L1-14 |
| 401121-R | VTM42-40-25-20-F07-R1-14 |
| 452625-L | VTM42-40-25-20-NO-L1-14 |
| 02-334403-R | VTM42-40-30-03-MF-R1-14 |
| 02-306408-R | VTM42-40-30-07-F11R1-14 |
| 398792-R | VTM42-40-30-07-MA-R1-14 |
| 574281-R | VTM42-40-30-07-NO-R1-14 |
| 385929-R | VTM42-40-30-10-F07-R1-14 |
| 398793-R | VTM42-40-30-10-NO-R1-14 |
| 426057-R | VTM42-40-30-12-N0-R1-14 |
| 401105-R | VTM42-40-30-15-F07-R1-14 |
| 385966-R | VTM42-40-30-15-MA-R1-14 |
| 431231-R | VTM42-40-30-15-N0-R1-14 |
| 02-136864-R | VTM42-40-30-20F07-R1-14 |
| 431226-R | VTM42-40-35-10-F11-R1-14 |
| 389403-R | VTM42-40-35-10-MD-R1-14 |
| 574203-R | VTM42-40-35-10-ME-R1-14 |
| 385927-R | VTM42-40-35-10-N0-R1-14 |
| 502850-R | VTM42-40-35-12-MB-R1-14 |
| 413674-R | VTM42-40-35-12-N0-R1-14 |
| 388935-R | VTM42-40-35-15-F11-R1-14 |
| 574206-R | VTM42-40-35-15-NO-R1-14 |
| 02-160183-R | VTM42-40-35-17-NO-R1-14 |
| 388930-R | VTM42-40-35-20-F11-*1-14 |
| 388815-R | VTM42-40-35-20-N0-R1-14 |
| 574279-L | VTM42-40-40-10-F07-L1-14 |
| 574279-R | VTM42-40-40-10-F07-R1-14 |
| 431167-R | VTM42-40-40-10-MA-R1-14 |
| 413741-R | VTM42-40-40-10-N0-R1-14 |
| 413666-R | VTM42-40-40-12-07-R1-14 |
| 413661-R | VTM42-40-40-12-F07-R-1-14-4 |
| 398745-L | VTM42-40-40-12-ME-L1-14 |
| 398745-R | VTM42-40-40-12-ME-R1-14 |
| 393182-R | VTM42-40-40-12-N0-R1-14 |
| 420739-R | VTM42-40-40-15-F11-R1-14 |
| 420856-L | VTM42-40-40-15-MB-L1-14 |
| 420856-R | VTM42-40-40-15-MB-R1-14 |
| 574847-R | VTM42-40-40-15-ME-R1-14 |
| 390833-L | VTM42-40-40-15-N0-L1-14 |
| 390833-R | VTM42-40-40-15-N0-R1-14 |
| 431160-L | VTM42-40-40-17-07L1-14 |
| 406346-R | VTM42-40-40-20-F07-R1-14 |
| 402272-R | VTM42-40-40-20-F11-R1-14 |
| 574324-R | VTM42-40-40-20-MA-*1-14 |
| 392097-R | VTM42-40-40-20-N0-R1-14 |
| 431144-R | VTM42-40-45-05-MF-R1-14 |
| 420885-R | VTM42-40-45-10-F11-R1-14 |
| 385968-R | VTM42-40-45-10-N0-R1-14 |
| 426097-R | VTM42-40-45-10-N0-R1-14-S54-S54-VTM42-40-45-10-N0-R1 |
| 452155-L | VTM42-40-45-12-MA-L1-14 |
| 388785-L | VTM42-40-45-15-MD-L1-14-S53-S53-VTM42-40-45-15-MD-L1 |
| 385969-L | VTM42-40-45-15-MDL1-14 |
| 413772-L | VTM42-40-45-15-N0-L1-14 |
| 413772-R | VTM42-40-45-15-N0-R1-14 |
| 388792-R | VTM42-40-45-15-N0-R1-14-S54-S54-VTM42-40-45-15-N0-R1 |
| 389390-L | VTM42-40-45-17-MD-L1-14-S53-S53-VTM42-40-45-17-MD-L1 |
| 388791-R | VTM42-40-45-17-N0-R1-14-S54-S54-VTM42-40-45-17-N0-R1 |
| 883014-R | VTM42-40-45-20-MD-R1-14-S4-S4-VTM42-40-45-20-MD-R1 |
| 574313-R | VTM42-40-4515-ME-R1-14-S53-53 |
| 574069-R | VTM42-40-50-10-NO-R1-14 |
| 574394-R | VTM42-40-50-12-07-R1-14 |
| 389410-R | VTM42-40-50-12-F11-R1-14 |
| 431101-R | VTM42-40-50-12-N0-R1-14 |
| 426083-R | VTM42-40-50-15-07-R1-14 |
| 431331-R | VTM42-40-50-15-F11-R1-14 |
| ME431187-L | VTM42-40-50-15-N0-L1-14 |
| 431187-L | VTM42-40-50-15-N0-L1-14 |
| ME431187-R | VTM42-40-50-15-N0-R1-14 |
| 431187-R | VTM42-40-50-15-N0-R1-14 |
| 452634-L | VTM42-40-50-20-MB-L1-14 |
| 431201-R | VTM42-40-55-15-F11-R1-14 |
| 574224-R | VTM42-40-55-15-F11-R1-14-S81-S81-VTM42-40-55-15-F11 |
| 574238-R | VTM42-40-55-15-ME-R1-14-S4-S4-VTM42-40-55-15-ME-R1 |
| 574105-R | VTM42-40-55-15-NO-R1-14 |
| 431150-L | VTM42-40-55-17-MB-L1-14 |
| 431150-R | VTM42-40-55-17-MB-R1-14 |
| 420773-L | VTM42-40-55-20-F11-L1-14 |
| 420773-R | VTM42-40-55-20-F11-R1-14 |
| 420857-R | VTM42-40-55-20-ME-R1-14 |
| 452154-R | VTM42-40-55-20-ME-R1-14-S4-S4-VTM42-40-55-20-ME-R1 |
| 574565-L | VTM42-40-55-20-N0-L1-14 |
| 574565-R | VTM42-40-55-20-N0-R1-14 |
| 426070-R | VTM42-40-55-21-F11-R1-14-S76-S76-VTM42-40-55-21-F11 |
| 574221-L | VTM42-40-55-21-F11-L1-14-S79-S79-VTM42-40-55-21-F11 |
| 574221-R | VTM42-40-55-21-F11-R1-14-S79-S79-VTM42-40-55-21-F11 |
| 574278-R | VTM42-40-60-10-NO-R1-14 |
| 02-160449-L | VTM42-40-60-15-F11-L1-14 |
| 02-160449-R | VTM42-40-60-15-F11-R1-14 |
| 477543-R | VTM42-40-65-10-F11-R1-14 |
| 431169-R | VTM42-40-65-10-MA-R1-14 |
| 431296-R | VTM42-40-65-10-N0-R1-14 |
| 420877-R | VTM42-40-65-15-N0-R1-14-S55-5-VTM42-40-65-15-N0-R1-14 |
| 02-102632-R | VTM42-40-65-17-F11-R1-14 |
| 02-151912-R | VTM42-40-65-17-M3-R1-14 |
| 385907-R | VTM42-40-65-20-MA-R1-14 |
| 850784-R | VTM42-40-65-20-ME-R1-14 |
| 385977-R | VTM42-40-65-20-NO-R1-14 |
| 413729-R | VTM42-40-75-10-F11-R1-14 |
| 426058-R | VTM42-40-75-10-N0-R1-14 |
| 388798-R | VTM42-40-75-15-F11-R1-14 |
| 385904-R | VTM42-40-75-15-N0-R1-14 |
| 385916-R | VTM42-40-75-20-ME-R1-14 |
| 385971-R | VTM42-40-75-20-NO-R1-14 |
| 431270-R | VTM42-402015-ME-R1-14-S4 |
| 420876-R | VTM42-404510-N0-R1-14-S55 |
| 431136-R | VTM42-405510-ME-R1-14-S4 |
| 452611-R | VTM42-50-15-10-F11-R1-14 |
| 402245-R | VTM42-50-20-12-F07-R1-14 |
| 412176-R | VTM42-50-20-15-MB-R1-14 |
| 574393-R | VTM42-50-20-20-N0-R1-14 |
| 401102-R | VTM42-50-30-10-N0-R1-14 |
| 426090-R | VTM42-50-30-12-F07-R1-14 |
| 574097-R | VTM42-50-30-15-NO-R1-14 |
| 385962-R | VTM42-50-30-20-MF-R1-14 |
| 574235-L | VTM42-50-35-05-ME-L1-14 |
| 574235-R | VTM42-50-35-05-ME-R1-14 |
| 420705-R | VTM42-50-35-12-N0-R1-14 |
| 385909-R | VTM42-50-35-20-ME-R1-14 |
| 574073-L | VTM42-50-40-09-N0-L1-14-S75-S75-VTM42-50-40-09-N0-L1 |
| 431180-R | VTM42-50-40-10-07-R1-14 |
| 393168-R | VTM42-50-40-10-MD-R1-14 |
| 402261-L | VTM42-50-40-10-N0-L1-14 |
| 402261-R | VTM42-50-40-10-N0-R1-14 |
| 02-348532-R | VTM42-50-40-12-MF-R1-14 |
| 420847-R | VTM42-50-40-12-N0-R1-14 |
| 420711-R | VTM42-50-40-15-07-R1-14 |
| 420758-L | VTM42-50-40-15-ME-LI-14-VTM42-50-40-15-ME-L1-14 |
| 452159-R | VTM42-50-40-15-ME-R1-14S4-S4 |
| 02-346003-R | VTM42-50-40-15-MF-R1-14 |
| 383364-R | VTM42-50-40-15-MF-R1-14-S4-S4 |
| 426094-L | VTM42-50-40-15-MJ-L1-14-S4-S4 |
| 574319-L | VTM42-50-40-15-MJ-L1-14-S84-S84-VTM42-50-40-15-MJ-L1 |
| 426022-L | VTM42-50-40-15-N0-L1-14 |
| 426022-R | VTM42-50-40-15-N0-R1-14 |
| 388802-R | VTM42-50-40-17-MF-R1-14-S4-S4-VTM42-50-40-17-MF-R1 |
| 503115-L | VTM42-50-40-17-MJ-L1-14-S4-S4-VTM42-50-40-17-MJ-L1 |
| 574398-L | VTM42-50-40-17-MJ-L1-14-S86-S86-VTM42-50-40-17-MJ-L1 |
| 452152-L | VTM42-50-40-20-MJ-L1-14-S4-S4-VTM42-50-40-20-MJ-L1 |
| 574409-L | VTM42-50-40-20-MJ-L1-14-S86-S86-VTM42-50-40-20-MJ-L1 |
| 404436-L | VTM42-50-40-20-N0-L1-14 |
| 404436-R | VTM42-50-40-20-N0-R1-14 |
| 452457-R | VTM42-50-40-20-N0-R1-14-S55-S55-VTM42-50-40-20-N0-R1 |
| 398742-R | VTM42-50-45-10-F11-R1-14 |
| 431163-L | VTM42-50-45-10-MF-R1-14-S4-S4-VTM42-50-45-10-MF-R1 |
| 426047-R | VTM42-50-45-10-N0-R1-14 |
| 426095-R | VTM42-50-45-12-N0-R1-14-S53-S53-VTM42-50-45-12-N0-R1 |
| 389416-L | VTM42-50-45-15-FS07-L113-S30-13-S30 |
| 389395-R | VTM42-50-45-15-N0-R1-14 |
| 02-143025-R | VTM42-50-45-17-NO-R1-14 |
| 386017 | VTM42-50-45-20-F07-R1-14-S56 |
| 386017-R | VTM42-50-45-20-F07-R1-14-S56 |
| 394314-R | VTM42-50-45-20-FS07-R1-14-4-VTM42-50-45-20-FS07-R1 |
| 385921-L | VTM42-50-45-20-MD-L1-14 |
| 876286-R | VTM42-50-45-20-MD-R1-14-S4-S4 |
| 875842-R | VTM42-50-45-20-ME-R1-14 |
| 385947-R | VTM42-50-45-20-N0-R1-14 |
| 574301-R | VTM42-50-50-07-NO-R1-14 |
| 413665-R | VTM42-50-50-10-F07-R1-14 |
| 413679-L | VTM42-50-50-10-MD-L1-14 |
| 413679-R | VTM42-50-50-10-MD-R1-14 |
| 389417-R | VTM42-50-50-15-F11-R1-14 |
| 388794-R | VTM42-50-50-15-N0-R1-14 |
| 431152-R | VTM42-50-50-17-07-R1-14 |
| 02-141771-L | VTM42-50-50-17-MJ-L1-14-S4-S4-VTM42-50-50-17-MJ-L1 |
| 386007-R | VTM42-50-50-17-N0-R1-14 |
| 574068-L | VTM42-50-50-20-ME-L1-14 |
| 02-143051-L | VTM42-50-50-20-MJ-L1-14-S4-S4 |
| 395018-R | VTM42-50-50-20-N0-R1-14 |
| 452174-R | VTM42-50-55-05-F07-R1-14 |
| 431391-R | VTM42-50-55-12-N0-R1-14 |
| 420878-R | VTM42-50-55-12-N0R114-S55-5-VTM42-50-55-12-N0R114 |
| 478270-R | VTM42-50-55-15-ME-R1-14-S4-S4-VTM42-50-55-15-ME-R1 |
| 02-125665-R | VTM42-50-55-15-N0-R1-14 |
| 452631-R | VTM42-50-55-17-ME-R1-14 |
| 02-160025-R | VTM42-50-55-17-NO-R1-14 |
| 574101-R | VTM42-50-55-20-NO-R1-14 |
| 452633-L | VTM42-50-65-17-MF-L1-14 |
| 413686-R | VTM42-50-75-10-N0-R1-14 |
| 385960-R | VTM42-50-75-20-N0-R1-14 |
| 412173-R | VTM42-60-15-15-N0-R1-14 |
| 02-102096-R | VTM42-60-15-20-N0-*1-14 |
| 398753-R | VTM42-60-20-10-N0-R1-14 |
| 02-142720-L | VTM42-60-20-15-F07-L1-14 |
| 02-142720-R | VTM42-60-20-15-F07-R1-14 |
| 431122-R | VTM42-60-20-15-F11-R1-14 |
| 574023-R | VTM42-60-30-10-F07-R1-14 |
| 426017-R | VTM42-60-30-10-N0-R1-14 |
| 420706-R | VTM42-60-30-15-N0-R1-14 |
| 502815-L | VTM42-60-30-20-N0-L1-14 |
| 502815-R | VTM42-60-30-20-N0-R1-14 |
| 02-348213-R | VTM42-60-35-10-NO-R1-14 |
| 477538-R | VTM42-60-35-15-N0-R1-14 |
| 401089-R | VTM42-60-40-10-F11-R1-14 |
| 503091-R | VTM42-60-40-10-ME-R1-14 |
| 431115-R | VTM42-60-40-10-N0-R1-14 |
| 404450-R | VTM42-60-40-12-N0-R1-14 |
| 389391-R | VTM42-60-40-15-F11-R1-14 |
| 385980-R | VTM42-60-40-15-N0-R1-14 |
| 389396-R | VTM42-60-40-17-N0-R1-14 |
| 453143-R | VTM42-60-40-17-N0-R13-14-S4-S4-VTM42-60-40-17-N0-R1 |
| 574014-L | VTM42-60-40-20-MA-L1-14 |
| 385908-R | VTM42-60-40-20-MB-R1-14 |
| 385888-R | VTM42-60-40-20-N0-R1-14 |
| 431369-R | VTM42-60-45-10-MB-R1-14 |
| 431283-R | VTM42-60-45-10-MF-R1-14 |
| 398740-R | VTM42-60-45-10-NO-R1-14 |
| 413744-R | VTM42-60-45-12-ME-R1-14 |
| 401099-R | VTM42-60-45-12-N0-R1-14 |
| 389051-R | VTM42-60-45-15-F11-R1-14 |
| 395017-R | VTM42-60-45-15-MF-R1-14 |
| 406350-R | VTM42-60-45-15-N0-R1-14 |
| 574315-L | VTM42-60-45-17-MJ-L1-14-S84-S84-VTM42-60-45-17-MJ-L1 |
| 574315-R | VTM42-60-45-17-MJ-R1-14-S84-S84-VTM42-60-45-17-MJ-R1 |
| 431190-R | VTM42-60-45-17-N0-R1-14 |
| 385895-R | VTM42-60-45-20-F07-R1-14 |
| 404439-R | VTM42-60-45-20-F11-R1-14 |
| 390820-R | VTM42-60-45-20-FS07-R1-14-4-VTM42-60-45-20-FS07-R1 |
| 390806-L | VTM42-60-45-20-FS07R1-13S30-S30 |
| 404433-R | VTM42-60-45-20-N0-R1-14 |
| 452612-R | VTM42-60-45-22-ME-R1-14-S4-S4-VTM42-60-45-22-ME-R1 |
| 431305-L | VTM42-60-50-10-F07-L1-14 |
| 431305-R | VTM42-60-50-10-F07-R1-14 |
| 413733-L | VTM42-60-50-12-N0-L1-14 |
| 413733-R | VTM42-60-50-12-N0-R1-14 |
| 388927-R | VTM42-60-50-15-F11-R1-14 |
| 431172-R | VTM42-60-50-15-MA-R1-14 |
| 431234-R | VTM42-60-50-15-ME-R1-14 |
| 386015-L | VTM42-60-50-15-N0-L1-14 |
| 386015-R | VTM42-60-50-15-N0-R1-14 |
| 574547-R | VTM42-60-50-17-F11-R1-14 |
| 426040-L | VTM42-60-50-17-N0-L1-14 |
| 426040-R | VTM42-60-50-17-N0-R1-14 |
| 02-346371-R | VTM42-60-50-20-ME-R1-14 |
| 394993-R | VTM42-60-50-20-NO-R1-14 |
| 383331-R | VTM42-60-55-10-MJ-R1-14 |
| 401108-R | VTM42-60-55-10-N0-R1-14 |
| 574106-R | VTM42-60-55-10-F11-R1-14 |
| 409545-R | VTM42-60-55-12-MD-R1-14-S4-S4 |
| 477537-R | VTM42-60-55-15-11R1-14 |
| 388939-R | VTM42-60-55-15-F11-R1-14 |
| 502648-R | VTM42-60-55-17-MB-R1-14-S82-S82-VTM42-60-55-17-MB-R1 |
| 02-125260-R | VTM42-60-55-20-MF-R1-14 |
| 389052-R | VTM42-60-55-20-N0-R1-14 |
| 413646-R | VTM42-60-60-12-F11-R1-14 |
| 388793-R | VTM42-60-60-12-N0-R1-14 |
| 396665-R | VTM42-60-60-15-MD-R1-14 |
| 406339-R | VTM42-60-60-15-N0-R1-14 |
| 420873-R | VTM42-60-60-20-NO-R1-14 |
| 431134-L | VTM42-60-65-10-F11-L1-14 |
| 431134-R | VTM42-60-65-10-F11-R1-14 |
| 574845-L | VTM42-60-65-10-NO-L1-14 |
| 574845-R | VTM42-60-65-10-NO-R1-14 |
| 431196-R | VTM42-60-65-15-07-R1-14 |
| 392070-R | VTM42-60-65-15-11-R1-14 |
| 393156-L | VTM42-60-65-15-F11-L1-14 |
| 393156-R | VTM42-60-65-15-F11-R1-14 |
| 385900-L | VTM42-60-65-15-MA-L1-14 |
| 413762-L | VTM42-60-65-15-MB-L1-14 |
| 413728-R | VTM42-60-65-15-ME-R1-14 |
| 431366-R | VTM42-60-65-15-MF-R1-14 |
| 404438-L | VTM42-60-65-15-N0-L1-14 |
| 404438-R | VTM42-60-65-15-N0-R1-14 |
| 426099-R | VTM42-60-65-15-NO-R1-14-S54-S54-VTM42-60-65-15-NO-R1 |
| 385936-R | VTM42-60-65-20-F07-R1-14 |
| 388926-R | VTM42-60-65-20-F11-R1-14 |
| 394325-R | VTM42-60-65-20-N0-R1-14 |
| 431333-R | VTM42-60-75-05-F11-R1-14 |
| 426087-R | VTM42-60-75-07-F07-R1-14 |
| 431149-R | VTM42-60-75-07-N0-R1-14 |
| 574284-L | VTM42-60-75-10-07-L1-14 |
| 392100-L | VTM42-60-75-10-F11-L1-14 |
| 392100-R | VTM42-60-75-10-F11-R1-14 |
| 502838-R | VTM42-60-75-12-F07-R1-14 |
| 388937-R | VTM42-60-75-12-F11-R1-14 |
| 409543-R | VTM42-60-75-12-N0-R1-14 |
| 388923-L | VTM42-60-75-15-11-L1-14 |
| 388923-R | VTM42-60-75-15-11-R1-14 |
| 385994-L | VTM42-60-75-15-F07-L1-14 |
| 388922-R | VTM42-60-75-15-F11-R1-14 |
| 388915-R | VTM42-60-75-15-F11-R1-14-S31-S31-VTM42-60-75-15-F11 |
| 385974-R | VTM42-60-75-15-MD-R1-14 |
| 574365-R | VTM42-60-75-15-ME-R1-14 |
| 385998-R | VTM42-60-75-15-N0-R1-14 |
| 393184-R | VTM42-60-75-17-N0-R1-14 |
| 388919-R | VTM42-60-75-20-F11-R1-14 |
| 385898-R | VTM42-60-75-20-ME-R1-14 |
| 385932-L | VTM42-60-75-20-N0-L1-14 |
| 385932-R | VTM42-60-75-20-N0-R1-14 |
| 412178-L | VTM42-60-N0-20-MF-L1-14 |
| 412178-R | VTM42-60-N0-20-MF-R1-14 |
| 574247-R | VTM42-10-15-05-N0-R1-14 |
| 574311-R | VTM42-10-15-10-N0-R1-14 |
| 02-466415-R | VTM42-20-45-10-NO-R1-14 |
| 574380-R | VTM42-20-65-10-ME-R1-14 |
| 385964-R | VTM42-40-30-12-MA-R1-14 |
| 574843-R | VTM42-40-45-10-NO-R1-14-S4 |
| 452609-L | VTM42-40-50-07-N0-R1-14 |
| 574269-R | VTM42-40-50-10-07-R1-14 |
| 574859-R | VTM42-50-15-05-N0-R1-14 |
| 02-341125-L | VTM42-50-55-17-F07-L1-14 |
| 02-466462-R | VTM42-50-55-17-MB-R1-14 |
| 404437-R | VTM42-50-55-20-ME-R1-14 |
| 02-136753-R | VTM42-50-55-20-ME-R1-14-S4-S4-VTM42-50-55-20-ME-R1- |
| 431299-R | VTM42-60-50-07-NO-R1-14 |
| 388924-R | VTM42-60-50-10-F11-R1-14 |
| 02-328951-R | VTM42A-40-20-12-MF-R38-14-4 |
| 431194-R | VTM42A-40-20-12-MJ-R5-14 |
| 02-322129-R | VTM42A-40-30-03-MF-R38-14-4-VTM42A-40-30-03-MF-R38 |
| 02-142086-L | VTM42A-40-55-20-ME-L38-14-090-4-090-VTM42A-40-55-20-ME |
| 452373-R | VTM42A-50-40-17-ME-R38-14 |
| 453167-L | VTM42A-60-40-17-ME-L38-14-4-VTM42A-60-40-17-ME-L38 |
| 02-348241-R | VTM42A-60-45-15-MF-R38-14-4-VTM42A-60-45-15-MF-R38 |
| 477544-R | VTM42A-40-20-12-NO-R1-14 |
| 02-318885-R | VTM42A-40-25-15-NO-R38-14-4 |
Bomba hidráulica de Rexroth da série A10VSO18, bomba de pistão axial variável
Série de alta pressão variável da bomba hidráulica A10VSO45 com vida útil longa
O ISO da série da substituição 0240D 0260D 0280D do elemento de filtro da pressão de Hydac aprovou
Exerça pressão sobre a série de Hydac 0800D 0900D 1320D 1500D do elemento de filtro da substituição
Linha do retorno elementos da série de Hydac 0240R para a linha filtro do retorno hidráulica
Série variável hidráulica do volume PVP16 das bombas de pistão de Parker Denison
Bombas de pistão variáveis do volume das bombas hidráulicas de Parker Denison da série PVP41
Bomba de pistão axial das bombas hidráulicas de Parker da série de PV140 PV180 disponível
